The Power Team C1006C is a 100-ton, single-acting, general-purpose hydraulic cylinder designed for heavy lifting, pushing, and pressing applications across industrial, construction, and maintenance environments. With a robust 6.625-inch stroke, this cylinder provides the travel needed for significant displacement tasks while delivering the strength and reliability that Power Team cylinders are known for.
Built from high-strength alloy steel, the C1006C features a single-acting spring-return design, making it easy to use and ideal for applications where powered retraction is not required. Its Power Team “Power Tech” corrosion-resistant treatment extends service life in demanding jobsite conditions, and the chrome-plated piston rod, internal wear band, and heavy-duty stop ring ensure durability under full load. Operating at 10,000 psi and equipped with Power Team’s standard 3/8” NPTF coupler, the C1006C integrates easily with high-pressure hydraulic pumps and hose systems.
Delivers massive lifting force suitable for structural work, bridge repair, infrastructure adjustments, and heavy machinery servicing.
Extends under hydraulic pressure and retracts automatically via internal spring.
Fast, simple operation with fewer hydraulic connections than double-acting cylinders.
Provides ample travel for lifting, pushing, aligning, and positioning tasks where multi-inch displacement is needed.
Heat-treated alloy steel body for long-term endurance.
Chrome-plated piston resists scoring and corrosion.
Power Tech surface treatment improves wear and abrasion resistance.
High-strength stop ring prevents over-travel and protects internal components.
Uses a standard 10,000 psi rating and 3/8″ NPTF female half-coupler.
Compatible with most Power Team, Enerpac, and Simplex pumps and accessories.
Retraction relies on spring force and the weight of the cylinder—not hydraulic return.
Not ideal for horizontal or inverted applications where controlled retraction is needed.
As a 100-ton cylinder, it is heavier and bulkier than mid-range models.
Side loading must be avoided to protect seals and extend service life.
Must be used with a 10,000 psi pump rated for high-tonnage cylinders.
The Power Team C1006C is well-suited for heavy-duty industrial operations:
Bridge lifting, jacking, and support work
Infrastructure repair and construction
Heavy equipment maintenance and alignment
Pressing, forming, and fabrication shop operations
Mining and steel plant maintenance
Machinery installation and multi-point lifting
Foundation and structural realignment tasks
Place cylinder on a solid, level, load-rated surface before operation.
Use with a properly matched 10,000 psi hydraulic pump.
Align the load directly over the center of the piston to avoid side loading.
Inspect hoses, fittings, and couplers before each use.
Avoid exceeding rated capacity—100 tons of force demands strict adherence to safety.
Retract fully before moving or repositioning the cylinder.
Follow all Power Team safety and maintenance guidelines for high-tonnage hydraulic equipment.
