High-Output Portable Power for 10,000 psi Hydraulic Systems
The Power Team PG554 is a rugged, gasoline-powered hydraulic pump designed to deliver reliable, high-flow performance for heavy lifting, jacking, and industrial hydraulic applications where electric power is not available. Built for demanding field conditions, the PG554 provides dependable 10,000 psi hydraulic pressure to operate cylinders, torque tools, pullers, and other high-pressure hydraulic equipment.
Engineered with a two-stage pumping system, the PG554 delivers rapid oil flow at low pressure for fast tool advance, then automatically shifts to high pressure for controlled lifting and precision work. Its heavy-duty steel frame, industrial-grade gasoline engine, and efficient cooling design make it well suited for construction, infrastructure, mining, and maintenance environments. Portable and field-ready, the PG554 is a reliable solution for mobile crews requiring powerful hydraulic performance.
Gasoline-powered operation – ideal for remote jobsites with no electrical supply
Two-stage hydraulic pump design for fast advance and controlled high-pressure output
10,000 psi maximum operating pressure compatible with most high-pressure hydraulic tools
Industrial-grade gasoline engine built for reliability and long service life
Heavy-duty steel frame protects components in harsh environments
High-efficiency filtration system helps extend pump and tool life
Compact, portable layout for easy transport and setup
Specification |
Imperial |
|---|---|
| Brand | Power Team |
| Max Flow | 55 in3/min |
| Reservoir Capacity | 5.63 gal |
| Oper. Pressure | 10000 psi |
| Cylinder Compatibility | Double-acting |
| Valve Operation | Manually Operated |
| Valve Type | 4W3P Tandem Center |
| Weight | 120 Ibs |
| Specification | Details |
|---|---|
| Pump Type | Gasoline Hydraulic Pump |
| Pump Design | Two-stage (high flow / high pressure) |
| Max Operating Pressure | 10,000 psi |
| Power Source | Gasoline engine |
| Hydraulic Compatibility | Single-acting & double-acting tools* |
| Hydraulic Porting | 3/8″ NPTF |
| Frame | Heavy-duty steel protective frame |
| Primary Use | Lifting, jacking, pressing, field hydraulics |
*Configuration depends on valve setup (manual or 4-way).
The Power Team PG554 is ideal for high-demand, mobile hydraulic applications, including:
Bridge lifting and structural jacking
Heavy equipment installation and alignment
Construction and infrastructure projects
Mining and quarry maintenance
Industrial pressing and pulling
Field service and plant maintenance
Remote worksites without electrical power
Delivers powerful hydraulic output anywhere gas power is available
Faster cycle times thanks to two-stage pumping
Durable design minimizes downtime in rough environments
Compatible with a wide range of Power Team hydraulic tools
Portable and easy to deploy for mobile crews
Power Team single-acting and double-acting cylinders
Hydraulic jacks and lifting systems
Pullers, spreaders, and cutters
Torque wrenches and tensioners
Presses and specialty hydraulic tools
Use only hoses, couplers, and tools rated for 10,000 psi.
Place pump on a stable, level surface before operation.
Ensure proper ventilation—gas engines must not be used indoors.
Inspect hoses, fittings, and fuel lines prior to use.
Keep hydraulic oil clean to protect seals and internal components.
Never exceed rated system pressure.
Follow Power Team’s maintenance schedule for engine and hydraulic components.
Gas-powered hydraulic pumps are the go-to solution for remote, high-tonnage lifting and industrial applications where electric power is unavailable. Below is a practical comparison of three popular professional-grade units from Power Team and Enerpac, helping you choose the right pump for your hydraulic cylinders and tools.
| Feature | Power Team PG554 | Power Team PG1200M-4D | Enerpac ZG5310MX-R |
|---|---|---|---|
| Pump Type | Gasoline Hydraulic Pump | Gas-Powered Hydraulic Pump | Gas Hydraulic Pump |
| Pump Design | Two-Stage (High Flow / High Pressure) | Two-Stage (High Flow / High Pressure) | Two-Speed |
| Max Operating Pressure | 10,000 psi | 10,000 psi | 10,000 psi |
| Cylinder Compatibility | SA / DA* | Double-Acting (4-Way Valve) | SA / DA (configuration dependent) |
| Valve Configuration | Manual / Optional | Integrated 4-Way Directional Valve | Manual / Optional |
| Usable Oil Capacity | Medium capacity | Large industrial reservoir | 2.5 gallons usable |
| Power Source | Gasoline Engine | Gasoline Engine | Honda Gas Engine |
| Porting | 3/8″ NPTF | 3/8″ NPTF | Enerpac High-Pressure Port |
| Primary Strength | Portability & versatility | Heavy-duty DA control | High flow + long run time |
| Best For | General field lifting | Large DA cylinders | High-volume lifting systems |
*SA = Single-Acting, DA = Double-Acting (depends on valve setup)
Best suited for:
General construction and maintenance
Medium to large single-acting cylinders
Mobile service crews
Job sites needing portability and simplicity
Why choose it:
A rugged, flexible pump that covers most lifting needs without excess complexity.
Best suited for:
Double-acting cylinders
Bridge jacking and structural alignment
Controlled retraction under load
Multi-point or synchronized lifting
Why choose it:
Integrated 4-way valve makes it ideal for precision lifting and positioning.
Best suited for:
Large-stroke cylinders
High-tonnage lifting systems
Long run times
Demanding industrial and infrastructure projects
Why choose it:
Large 2.5-gallon reservoir + Honda engine = excellent endurance and fast cycle times.
Renting saves cost and ensures you get the correct pump configuration for each project.
Yes, when properly configured and used with the correct rated equipment and safety procedures.
They can. Hydraulic Rentals can provide complete rental packages including hoses, couplers, and gauges.
The pump size depends on cylinder capacity, stroke length, and oil volume requirements.
