High-Performance Gas Power for Demanding Hydraulic Applications
The Enerpac ZG5310MX-R is a rugged, high-output two-speed gas-powered hydraulic pump engineered for heavy-duty field operations. With a 2.5-gallon usable oil capacity and a compact 7.1 ft-lbs Honda motor, this pump delivers fast cycle times, exceptional reliability, and the versatility needed for remote or high-demand job sites.
High-Performance Gas Power for Demanding Hydraulic Applications
Designed for powering single-acting or double-acting cylinders, lifting systems, tools, and high-pressure applications, it’s built for professionals who need portable power with Enerpac’s legendary durability.
⭐ Key Features
Two-speed pump design for fast tool advance and controlled high-pressure operation
Powered by a Honda gas engine (7.1 ft-lbs torque) – industry standard for reliability
2.5-gallon usable oil reservoir for long run cycles and high-volume cylinders
Rugged roll-cage frame protects components on harsh job sites
Hydraulically-efficient system for consistent 10,000 psi output
Good for remote locations with no access to electricity
Reduced operator fatigue thanks to smooth two-speed performance
Maximum Operating Pressure 10,000 psi
Cylinder Compatibility Single-acting
Reservoir Capacity 578 in³
Usable Oil Capacity 2.5 gal
Maximum Flow at Rated Pressure 100 in³/min
Output Flow Rate 100 psi 700 in³/min
Output Flow Rate 700 psi 650 in³/min
Output Flow Rate 5000 psi 110 in³/min
Output Flow Rate 10000 psi 100 in³/min
Motor Manufacturer Honda
Motor Size 7.1 ft/lbs (4,1 kW)
Valve Function Advance / Hold / Retract
Valve Operation Manual
Valve Type 3-way, 3-position, Tandem Center
Valve Model VM33
Power Source Gasoline
Pump Control Manual
Sound Level 88 – 93 dBa
Relief Valve Adjustment Range1,000 – 10,000 psi
Weight 113.6 lbs
| Specification | Details |
|---|---|
| Pump Type | Two-Speed Gas Hydraulic Pump |
| Usable Oil Capacity | 2.5 gallons (9.5 L) |
| Motor Type | Honda Gas Engine |
| Engine Torque | 7.1 ft-lbs |
| Max Operating Pressure | 10,000 psi (700 bar) |
| Flow Rate (Low Pressure) | High-flow for fast tool advance |
| Flow Rate (High Pressure) | Reduced flow for precise control |
| Compatibility | Single-acting & double-acting cylinders |
| Ideal Use | Lifting, jacking, torque tools, industrial maintenance |
| Frame | Protective heavy-duty roll cage |
Heavy lifting and jacking systems
Bridge, infrastructure & construction projects
Rail, mining, and power generation applications
Large cylinders (50–500 ton)
Remote field operations
Torque wrench or puller systems
Long run time due to large reservoir
Dependable Honda power even in cold or rough environments
Less downtime thanks to Enerpac’s efficient two-speed design
Portable but strong enough for high-tonnage applications
Low-maintenance and field-serviceable
Enerpac single-acting and double-acting cylinders
Pullers, torque wrenches, spreaders
Jack-up and lifting systems
Hydraulic presses and cutters
Gas Hydraulic Pumps are designed for continuous-duty operation within rated pressure and flow limits when properly maintained.
Gas Hydraulic Pumps require routine engine servicing and hydraulic oil inspection, which is handled as part of professional rental maintenance programs.
Gas Hydraulic Pumps are typically mounted in protective steel frames with lifting points or wheels for jobsite mobility.
Gas Hydraulic Pumps are safe for heavy lifting when used with compatible cylinders, proper hose assemblies, pressure gauges, and integrated relief valves.
