🔄 Temporary, Permanent & Transfusion Applications
Flat jack systems can be configured for different engineering purposes. Understanding the intended application is essential when selecting the correct equipment.
Temporary hydraulic applications
Temporary hydraulic flat jacks are used where lifting, adjustment or a controlled change in load is required for a defined period. Depending on the operation, the jack may be depressurised and removed once the work is complete.
Permanent installations
For permanent applications, a suitable flat jack may be installed and filled using the specified injection procedure. The completed installation is intended to maintain the required structural force or load in accordance with the engineering design.
Transfusion systems
A transfusion arrangement is a specialist method in which a temporary hydraulic load is transferred to a permanent grout-filled load arrangement. The system and operating sequence must be designed for the particular application.
These approaches involve different equipment and procedures. The correct choice depends on the structural requirement, the flat jack design and the installation method specified for the job.
📏 Flat Jack Capacities, Shapes & Installation Heights
Flat jacks are available in a range of capacities and dimensions to suit different engineering requirements.
The available range includes capacities from approximately 1 ton to 1,240 tons, with certain models offering installation heights as low as 1.2 inches. These figures describe the overall range; not every capacity is available in every shape or installation height.
Round and rectangular flat jacks are available. The appropriate configuration depends on the load distribution, contact area, available space and structural arrangement.
When selecting a flat jack, consider:
- Required capacity: The load the unit must support or transfer.
- Installation height: The available gap in which the jack must fit.
- Stroke: The required lifting or adjustment movement.
- Shape and contact area: The configuration needed to suit the application.
- Operating method: Hydraulic lifting, permanent filling or another specified arrangement.
- Supporting equipment: The compatible pump, injection cylinder system, hoses and connections.
Providing accurate project information helps establish which equipment is appropriate and whether the required configuration is available.
🧰 What Equipment Is Needed to Operate a Flat Jack?
The equipment required depends on the type of flat jack and the intended operation. A conventional hydraulic lifting application may require a compatible hydraulic pump, hoses and connections. An injection-based application may require a suitable injection cylinder system and additional equipment specified for the filling procedure.
Before arranging a rental or purchase, establish the complete equipment requirement rather than selecting the flat jack in isolation.
The system may need to be checked for:
- Compatibility between the jack and the power or injection source.
- Required operating pressure and capacity.
- Connection and hose specifications.
- Required stroke and installation clearance.
- The intended working fluid or filling material.
- Any specialist controls, tooling or installation equipment.
The equipment must be operated within its specified limits and in accordance with the manufacturer’s instructions and the project’s engineering requirements.
🏢 Flat Jack Equipment Rental & Purchase Options
Different parts of a flat jack system may have different supply arrangements. Identifying these differences at the outset helps ensure that the equipment specification matches the project budget and operating requirements.
Hydraulic flat jacks
Hydraulic flat jacks may be available for rental, depending on the required model, capacity, dimensions and application.
Pumps, tools and accessories
The availability of pumps, tools, hoses and other supporting equipment depends on the particular system and the components required.
Injection cylinder systems
Injection cylinder systems can be rented or purchased, subject to the required specification and availability.
Grout-filled flat jacks
Grout-filled flat jacks for permanent installations are supplied for purchase rather than rental.
If you are unsure which arrangement is appropriate, provide the project details and identify whether the requirement is for temporary lifting, a permanent installation or a specialist transfusion system.
📋 Information Required for a Flat Jack Equipment Enquiry
To help identify the correct equipment, provide as much of the following information as possible:
- Application: What needs to be lifted, adjusted, supported or preloaded?
- Required capacity: The specified load in tons.
- Available installation height: The maximum height available for the jack, in inches.
- Required stroke: The lifting or adjustment movement needed, in inches.
- Jack configuration: Round, rectangular or another specified design.
- Operating method: Temporary hydraulic operation, permanent grout-filled installation or transfusion.
- Equipment required: Flat jack only, pump and accessories, injection cylinder system or a complete equipment arrangement.
- Rental or purchase: Which supply option is required for each component.
- Project location and timing: Where and when the equipment is needed.
Drawings, specifications, photographs and engineering notes can help clarify the requirements. Final equipment selection should be based on the actual load conditions, the manufacturer’s specifications and the applicable engineering design.
📞 Flat Jack Equipment & Systems
Whether you require hydraulic flat jacks for a temporary structural operation, pumps and tools to operate them, an injection cylinder system, or grout-filled flat jacks for a permanent installation, selecting the correct equipment is essential.
Custom Rentals can help you identify the equipment required for your application and establish which items are available for rental or purchase.
Call 866-522-5464 or request a quote online with your load requirements, installation dimensions and project details.
The more information you provide, the easier it is to identify a suitable flat jack configuration and the supporting equipment needed to complete the job.
